All-Terrain Surfer
| Remote controller | Gearbox
& chain drive system |
||
 Available one hand speed and brake control. Patent pending. |
 Equipped with chain and ratchet sprocket power train system. |
||
| Front spring hinge | Balance Strap & Foot hold | ||
|
|
 The balance strap helps keep you on board and is also used to carry the surfer. The optional foot holds keep your feet from slipping off. |
||
| Aluminum and wood deck. | 1.5 Liter fuel tank& bumper | ||
 Deck is constructed of light weight wood and aluminum. |
 A larger tank allows for rides up to 30 miles and is protected by a chrome plated bumper. |
||
 |
The Mitshibisi
designed, 33cc 2Stroke engine is compact and provides
strong power with low noise *The 4 stroke engine is available on the special deluxe model that requires no oil mixture. |
| Specifications | |
| Engine Type | Single cylinder, air-cooled, 2-stroke |
| Engine Displacement | 32.6cc |
| Horse Power | 1.7 @ 7000 rpm |
| Carburetion | Pumper type w/ choke & primer |
| Fuel | Unleaded gasoline / oil mix. |
| Fuel Capacity | 1.5 litre |
| Running Duration | 2-4 hours |
| Transmission | 78mm auto clutch, gear reduction, chain drive |
| Maximum Speed | 22 mph |
| Minimum Speed | 0 mph |
| Maximum Load | 350 lbs |
| Wheel Type | 9" pneumatic |
| Braking | Rear (band) |
